Ensure reliable burner ignition and combustion safety in boilers or gas-fired heating appliances with the Resideo (Honeywell Home) S8670E3003/B ignition module. Built for intermittent pilot ignition systems, this module offers robust pre‑purge sequencing, precise flame detection, and continuous retry after lockout.
Specifications:
- Type: Ignition Module
- Dimensions: 3-15/16″ high x 5-7/16″ wide x 2-5/8″ deep
- Electrical Ratings: 24 VAC
- Frequency: 60 Hz
- Approvals, Canadian Standards Association: Design Certified
- Flame Failure Response Time: 2 Seconds maximum
- PrePurge: 30 Seconds
- Temperature Range: -40°F to +175°F
- Ignition System Type: Intermittent Pilot
- Typical Gas Control: VR8204, VR8304
- Type of Gas: Natural or LP
- Flame Sense: Single Rod
- Ignition Trial Time: 90 Sec
- Maximum Valve Load @ 24 Vac (Amps): 1A Pilot, 2A Main @ 24Vac
- Typical Ignition Hardware: Q345, Q3451
- Between Trial Time (sec): 5 minute delay after failed trial for ignition
