The IDEC RTE-P1AD24 is a versatile, power-triggered analog timer from the RTE Series, engineered for reliable time-controlled switching in demanding electrical and HVAC control applications. With dual DPDT contacts and a wide range of operating modes, this timer delivers the flexibility and dependability professionals require.
Key Features
- Input Voltage: 24Vac / 24Vdc — compatible with a broad range of control circuits
- Contact Configuration: 2-DPDT (Double Pole Double Throw) for versatile switching capability
- Trigger Type: Power Triggered — initiates timing sequence upon power application
- Multiple Timing Functions: ON-delay, Interval, Cycle OFF, and Cycle ON modes
- Analog time setting for straightforward, tool-free adjustment
- 8-Pin terminal configuration for easy installation and wiring
- Compact form factor fits standard relay sockets
Timing Functions
- ON-Delay: Output activates after a set time delay following power application
- Interval: Output energizes immediately and de-energizes after the preset time period
- Cycle OFF: Continuous cycling with output beginning in the OFF state
- Cycle ON: Continuous cycling with output beginning in the ON state
Specifications
- Brand: IDEC
- SKU: RTE-P1AD24
- Series: RTE
- Input Voltage: 24Vac / 24Vdc
- Contact Type: 2-DPDT
- Terminal Type: 8-Pin
- Trigger Method: Power Triggered
- Timer Type: Analog
